PRICE LIST (MULTI CORE COPPER CABLE)ANODE ELECTRIC PVT. LTD.
Manufacture/Importer: Anocab |
|
|||||||||||||
| GSTIN: 23AANCA7455R1ZX | Mail: sales@anocab.com | Contact No: 18002700075 | ||||||||||||
| MULTI CORE COPPER CABLE | ||||||||||||||
| Image | Size(SQ MM) | No. of Wires & Dia Of Each Wire | Current Carrying Capacity | CR @ 20°C (Ω/km) | MRP | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| IN MM | IN INCH | BUNCHED AND ENCLOSED IN CONDUIT OR TRUNKING | CLIPPED DIRECT TO A SURFACE OR ON A CABLE TRAY, BUNCHED & ENCLOSED | (Ω/km) | 2 CORE | 3 CORE | 4 CORE | |||||||
| 2 CORE CABLE | 3/4 CORE CABLE | 2 CORE CABLE | 3/4 CORE CABLE | FLAT | ROUND | ROUND | ROUND | |||||||
|
||||||||||||||
| 0.5 | 16/0.20 | 16/0.00788 | 4 | 4(1-Φ) | - | - | 39.00 | - | - | - | - | |||
| 0.75 | 24/0.20 | 24/0.00788 | 7 | 7(1-Φ) | - | - | 26 | - | - | - | - | |||
| 1.0 | 32/0.20 | 32/0.00788 | 10 | 9 | 12 | 10 | 19.50 | - | - | - | - | |||
| 1.5 | 30/0.25 | 30/0.00985 | 13 | 11 | 16 | 14 | 13.30 | - | - | - | - | |||
| 2.5 | 50/0.25 | 50/0.00985 | 17 | 15 | 20 | 18 | 7.98 | - | - | - | - | |||
| 4 | 56/0.30 | 56/0.01181 | 22 | 20 | 27 | 24 | 4.95 | - | - | - | - | |||
| 6 | 84/0.30 | 84/0.01181 | 28 | 25 | 34 | 30 | 3.30 | - | - | - | - | |||
| TERMS AND CONDITIONS* | ||||||||||||||
|
*The above rates are GST Paid Rate *Freight Charges & any other statuory levies which shall be charged extra. *Delivery : F.O.R. destination by road transport for order value above Rs. 5,00,000/- *On To Pay basis for order values up to Rs. 5,00,000/- |
||||||||||||||
| PRODUCT DESCRIPTION | ||||||||||||||
|
*Reference : IS 694:2010. *Conductor : Electrolytiv grade annealed copper Class 5 as per IS 8130. *Insulation : PVC Type-A, HR PVC Type-C, as per IS 5831. *Colour of core : Red and Black for two core cable, Red, yellow and Blue for 3 Core Cable, Red , Yellow, Blue and Black for 4 core cable. *Sheath : PVC Type ST-1, PVC Type ST-2 as per IS 5831. *Colour of Sheath : Black and Other Colour as per Customer Demand. *Voltage Rating : Upto and including 450/750V. *Packing and Marking : Standard packing of 100/300/500 mtr. in coil. and Other length available on request, Cables are printed with the marking of 'ANOCAB'. |
||||||||||||||
|
||||||||||||||
| *THE PRICES ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE* | ||||||||||||||
