PRICE LIST (AUTOMOBILE WIRE)ANODE ELECTRIC PVT. LTD.
Manufacture/Importer: Anocab |
|
|||||||
| GSTIN: 23AANCA7455R1ZX | Mail: sales@anocab.com | Contact No: 18002700075 | ||||||
| AUTOMOBILE WIRE | ||||||||
| Image | Size (SQ MM) | No. Of Wires/ Wire Size | Bare Conductor CR at 20°C (Ω/km) | Tinned Conductor CR at 20°C (Ω/km) | Current Carrying Capacity | MRP | ||
|---|---|---|---|---|---|---|---|---|
 |
0.35 | 12/0.20 | 52 | 54.5 | 11 | - | ||
| 0.5 | 16/0.20 | 37.1 | 38.2 | 13 | - | |||
| 0.75 | 24/0.20 | 24.7 | 25.4 | 17 | - | |||
| 1 | 32/0.20 | 18.5 | 19.1 | 21 | - | |||
| 1.5 | 30/0.25 | 12.7 | 13.0 | 27 | - | |||
| 2.5 | 50/0.25 | 7.6 | 7.8 | 38 | - | |||
| 4.0 | 56/0.30 | 4.7 | 4.8 | 52 | - | |||
| 6.0 | 84/0.30 | 3.1 | 3.2 | 67 | - | |||
| TERMS AND CONDITIONS | ||||||||
|
*The above rates are GST Paid Rate. *Freight Charges & any other statuory levies which shall be charged extra. *Delivery : F.O.R. destination by road transport for order value above Rs. 5,00,000/- *On To Pay basis for order values up to Rs. 5,00,000/- |
||||||||
| PRODUCT DESCRIPTION | ||||||||
|
*Reference : DIN 72551 Pt-6 FLRY-B. *Test Voltage : 3000 Volts. *Conductor : Class-B according to DIN 13602. *Insulation : Plasticized PVC with properties according to DIN 72551 & ISO 6722, Lead free. |
||||||||
|
||||||||
| *THE PRICES ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE* | ||||||||
