PRICE LIST (ALL ALLOY ALUMINIUM CONDUCTOR)ANODE ELECTRIC PVT. LTD.
Manufacture/Importer: Anocab |
|
|||||||
| GSTIN: 23AANCA7455R1ZX | Mail: sales@anocab.com | Contact No: 18002700075 | ||||||
| ALL ALUMINIUM ALLOY CONDUCTOR | ||||||||
|---|---|---|---|---|---|---|---|---|
| Image | Conductor Name | Size (SQ MM) | Approx Wt (KG/KM) | No. of Wire / Al. Wire Size | Breaking Load (kN) | Resistance at 20°C (Ω/km) | MRP | |
 |
||||||||
| MOLE | 15 | 40.150 | 3/2.50 | 4.33 | 2.3040 | - | ||
| SQUIRREL | 22 | 60.160 | 7/2.00 | 6.45 | 1.5410 | - | ||
| WEASEL | 34 | 94.000 | 7/2.50 | 10.11 | 0.9900 | - | ||
| RABBIT | 55 | 149.200 | 7/3.15 | 16.03 | 0.6210 | - | ||
| RACCOON | 80 | 218.260 | 7/3.81 | 23.41 | 0.4250 | - | ||
| DOG | 100 | 272.860 | 7/4.26 | 29.26 | 0.3390 | - | ||
| TERMS AND CONDITIONS* | ||||||||
|
*The above rates are GST Paid Rate *Freight Charges & any other statuory levies which shall be charged extra. *Delivery : F.O.R. destination by road transport for order value above Rs. 5,00,000/- *On To Pay basis for order values up to Rs. 5,00,000/- |
||||||||
| PRODUCT DESCRIPTION | ||||||||
|
*Reference : IS-398(PT-4):1994 *Conductor : Conductor Containing All Aluminium Alloy Wire in Concentric Layer. *Resistivity : Resitivity of Material MAX> 0.0328 Ohm MM2/m at 20oC. |
||||||||
|
||||||||
| *THE PRICES ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE* | ||||||||
